MODEL FEATURES
- Cooler running, outboard bearing provides maintenance-free operation
- Environmentally friendly oil-free technology
- Extremely quiet operation
- All motors are standard TEFC with Class F insulation, UL recognized, CE Compliant
- Rugged die cast aluminum construction
Selection & Ordering Data - Type 3BA1500
| Curve No. | Order No. | Hz | HP | Input | Input | Permissible total differential pressure2 | Sound pressure level3 | Weight (lbs.) | |||
Vacuum inch H2O | Compressor | dB(A) | |||||||||
| 3~ 50/60 Hz IP55 insulation material class F | |||||||||||
| A 190 | 3BA1500-7AT06 | 50 | 1.14 | 200D… 240D | 345Y…415Y | 4.2D | 2.4Y | -44 | 40 | 64 | 40 |
| A 191 | 3BA1500-7AT06 | 60 | 1.27 | 220D… 250D | 415Y…460Y | 4.35D | 2.5Y | -32 | 28 | 70 | 40 |
| A 192 | 3BA1500-7AT16 | 50 | 1.74 | 200D… 240D | 345Y…415Y | 5.7D | 3.3Y | -68 | 68 | 64 | 44 |
| A 193 | 3BA1500-7AT16 | 60 | 2.0 | 220D… 250D | 415Y…460Y | 5.5D | 3.2Y | -60 | 56 | 70 | 44 |
| A 194 | 3BA1500-7AT26 | 50 | 2.14 | 200D… 240D | 345Y…415Y | 7.5D | 4.3Y | -80 | 76 | 64 | 46 |
| A 195 | 3BA1500-7AT26 | 60 | 2.75 | 220D… 250D | 415Y…460Y | 7.5D | 4.4Y | -88 | 84 | 70 | 46 |
| A 196 | 3BA1500-7AT36 | 50 | 2.95 | 200D… 240D | 345Y…415Y | 9.7D | 5.6Y | -88 | 108 | 64 | 55 |
| A 197 | 3BA1500-7AT36 | 60 | 3.42 | 220D… 250D | 415Y…460Y | 9.0D | 5.3Y | -104 | 116 | 70 | 55 |
DIMENSIONS
Relief valve:
VC61Z (Vacuum)
PC61Z (Pressure)
Filter:
ATF-200-15124/1
(Vacuum)
AFS-30-200-10
(Pressure)
PERFORMANCE CURVE FOR VACUUM PUMP
PERFORMANCE CURVE FOR COMPRESSOR
Standard Factory Warranties Apply.
